Maxhub Trolley Up Down Tilt

Features:

Maxhub Motorised AV Trolley for Interactive Displays

• Up/Down plus flip angle to 90 degrees for tabletop use
• The EST11 has one of the largest ranges of movement currently available in motorised trolleys
• It is robust and yet elegant in its design and allows for both up/down movement as well as the ability to flip to 90 degrees for tabletop use of the panel
• EST11 is easy to assemble and comes packaged with everything you will need
• The best part is that you can raise and lower the trolley all from an application on the interactive display itself

Specification:

• Dimension Assembled: 1178(L) x 741(W) x (1056 to 1706)(H)mm
• Package Dimension: 1305(L) x 825(W) x 205(H)mm
• Power Requirements: AC 100-240V, 50/60hz
• Power Consumption(Typical): 135W
• Power Consumption (Max): 300W
• Motor travel speed: 35mm/s
• Lifting Distance: 650mm
• Flip Angle: 90 degree +- 1 degree
• Gross Weight: 57kg
• Net Weight: 46kg
• Max Load: 100kg
• Max LRecommend Panel Size: Up to 86 inch only
• Control Mode: Control Panel /Control Pad / Software
• Castors: 4 Inches Mute
• Support Wall-hanging: Standard Dedicated Wall Mount
• Package Includes: AC Power Cable x 1; USB Adapter Cable x 1; Hand Controller x 1; Holder For Hand Controller x 1; Screw Accessory Package x 1; Installation Manual x 1; User Guide x 1
• OEM: EST11
